M&M 10 Amp Pressure Switch 1.5 - 4.0 Bar
Product Code: XP73DE61.000
...
Available to Order
tech sheet 975
Details
Compound Gauge bar
1.5 to 4.0
Working Temperature
-10°C to +125°C
Thread Type
BSPT
Material
Brass
Repeatability bar
°0.2
Fixed Differential bar
0.20 ° 0.1
Thread Gender
Male
Brand
M&M
Thread Size
1/8"
Specification
1/8" BSP Tapered Male, Direct Mount Pressure Switch, Brass Suitable for Water, Steam & Aggressive Media, Brass, 10amp, Working Temperature -10°C to +125°C, Fixed Differential Dial 0.20 ± 0.1 bar, Repeatability ±0.2 bar, Compound Gauge 1.5 to 4.0 bar, M&M
Features: Available in brass or stainless steel body. BSPT threads. 250V AC 10A SPDT contact. IP45 rated with cap.
Additional Variants
Product Name
Product Code
Compound Gauge bar
Repeatability bar
Fixed Differential bar
Buy Price
1.0 to 2.5
°0.2
0.20 ° 0.1
£66.63
Available to Order
0.2 to 1.2
°0.15
0.20 ° 0.1
£64.38
Available to Order
2.0 to 6.0
°0.2
0.30 ° 0.1
£60.19
Available to Order
